Archives of Past Exhibits:MANN+HUMMEL

2015 IAA Frankfurt Motor Show

Filter element with three-stage water separation system

-Three stage system involves the filtration of particles, capture of water (due to different densities) by a coalescer which merges the water in larger droplets, and then separation of the water from the fuel with a hydrophobic sieve.

Air cleaner with Flexline filter element

Air cleaner with conventional air filter element

Microscopic model of cabin air combination filter medium

Microscopic model of cabin air particle filter medium

Cabin air filter

-Installed in Volvo vehicles

FreciousPlus filter

-Installed in VW vehicles

Cabin air filter

-Installed in Ford vehicles

Air cleaner system

-Installed in Fiat-Chrysler vehicles

Soundpipe

-Installed in Ford vehicles

Symposer

-Installed in Jaguar vehicles

Air cleaner system

-Installed in Ford vehicles

Active intake manifold system with integrated charge air cooler and eBooster system

-Collaboration with BorgWarner

Air cleaner system

-Installed in BMW vehicles

Air induction system

-Installed in PSA vehicles

Air cleaner system

-Installed in Renault and Nissan vehicles

Oil filter module

-Installed in VW vehicles

Oil filter module

-Installed in FAW vehicles

Spin-on oil filter

-Installed in VW vehicles

Oil filter module

-Installed in Audi vehicles

Sealing system prototype for liquid filter modules under high pressure

Oil filter module

-Installed in Daimler vehicles

Fuel filter module

-Installed in Audi vehicles

Fuel filter module

-Installed in Audi vehicles

Water separator

Fuel filter module

-Installed in GM vehicles

Fuel filter module prototype with integrated control unit

Intake manifold

-Installed in GM vehicles

Intake manifold

-Installed in VW vehicles

Active charge air duct prototype

Charge air duct

-Installed in Great Wall vehicles

Charge air duct with agile joint

-Installed in BMW vehicles

Degassing unit for high-voltage batteries

-Installed in BMW vehicles

Cylinder head cover

2015 Int'l Rechargeable Battery Expo (BATTERY JAPAN)

Ion exchange filter

Liquid-cooled Li-Ion battery tray

Installed Vehicle： Chevrolet　Volt

Cathode air filter

Degassing unit

2014 JSAE Automotive Engineering Exposition

Air intake manifold

Installed Vehicle： Mercedes-Benz

Air cleaner

Installed Vehicle：VW

Symposer

Installed Vehicle： Porsche

Oil Filter

Installed Vehicle： GM

Fuel Filter

Installed Vehicle：GM

Hot gas welding

Installed Vehicle：VW

2013 IAA Frankfurt Motor Show

Symposer

Installed Vehicle： Porsche

Soundpipe

Installed Vehicle： Porsche

Active Noise Control System

Symposer

Installed Vehicle： Ford

Battery Frames

Installed Vehicle： GM

EGR

Active Cooling Thermomanagement Valve

Installed Vehicle： PSA

Intake Manifold

Installed Vehicle： GM

Intake Manifold

Installed Vehicle： Maruti Suzuki

Intake Manifold with fully integrated Charge Air Cooler

Oil Separator

Air Filter

Heating Pipe

Ion Exchange Filter

Air Cleaner with Broad Band Silencer

Installed Vehicle： Land Rover

Oil Filter

Air Cleaner

Installed Vehicle： Daimler

Air Cleaner

Installed Vehicle： Ford

Fuel Filter

Installed Vehicle： GM

2011 IAA Frankfurt Motor Show

Air Cleaner System with Orifice Flap

Ford Sound Pipe

Battery holder

Installed Vehicles： Chevrolet "Volt"

Renault Air/Exhaust Gas Mixer (EGR Mixer)

Active Cooling Thermomanagement Valve (ACT-Valve)

Plastic Timing Case Cover

BMW Charge Air Duct "cold Side"

Maruti Suzuki Intake Manifold

Installed Vehicles： Maruti Suzuki

Maruti Suzuki Air Cleaner

Installed Vehicles： Maruti Suzuki

Mahindra Crankcase Ventilation System

Installed Vehicles： Mahindra

GM Air Cleaner System

Oil Separator with Pressure Control Valve

Cylinder Head Cover with Oil Separator

Daimler Intake Manifold and Air Cleaner

Volvo Diesel Fuel Filter

Filter Concept for Water Separation in modern Diesel Fuels

Fuel Filter

Ford Oil Filter Module

Audi Oil Filter with Housing

Daimler Oil Filter Module

Volvo Oil Filter

BMW Oil Filter

Air Filters

PSA Air Cleaner with blow-molded Clean Air Duct

Daimler Cabin Air Filter "Frecious Plus"

PSA Air Cleaner with blow-molded Clean Air Duct

Land Rover Air Cleaner

Suzuki Air Cleaner

China International Auto Products Expo 2010

Changchun Mann + Hummel FAWAY Filter Co., Ltd. Oil separator

For Weichai engine

Changchun Mann + Hummel FAWAY Filter Co., Ltd. Fuel strainer assembly

Installed vehicles : FAW Jiefang "J5", "J6"

Changchun Mann + Hummel FAWAY Filter Co., Ltd. Air filter assembly

Installed vehicle : FAW Mazda "Mazda 6"

Delhi Auto Expo 2010

Truck air intake system

Customer : Tata Motors

Intake manifold

Customer : GM Korea

Oil filter module

Customer : Volvo

Cylinder head cover

Customer : Volkswagen

Air cleaner system

Customer : GM

Air cleaner

Customer : Toyota

Sound pipe

Customer : Ford

Symposer

Customer : Jaguar

Washer reservoir

Customer : BMW

SAE World Congress 2006

<Highlights>
Highlights of the 2006 product display include the following two products
New oil filter module (All plastic)
All recyclable
Installed on the 2.5L VW
Fully plastic oil module, incorporating a cooler, crankcase ventilation system, sensors, regulating valves, metal-free oil filter and a drain system.
Symposer
Developed by DaimlerChrysler, Ford and the Company.
Mass-production will commence in the ST sports version of the European Ford Focus with a 2.5 litre, 5 cylinder turbocharged gasoline engine.
The symposer, a cube 6 cm x 5cm x 4cm in size, is made up of four chambers. A moveable flap separates the two chambers on the engine side from the two chambers on the outlet side. The pulsations generated by the engine meet the pivoted flap, producing oscillation of the spring-mass system which is then transferred to the outlet chambers. The pulsations are transmitted by means of a sound pipe through the partition wall into the passenger compartment, thus creating the desired charge-dependent feedback.

Tokyo Motor Show 2005

<Highlights>
Diesel Air Intake Module Audi V8 TDI
Air intake module with EGR system
This system, made of plastic that is easy to form, was made much lighter than previous systems. It also has superior properties in terms of corrosion-protection against sulfur oxide emitted in EGR process. The polyamide material, co-jointly developed with Audi, can withstand very high temperatures, over 200 degrees, for long periods of time. The module consists of an EGR valve, EGR cooler, regulation valve, and flange with swirl & tumble control unit.
>>Technical Information

Oil Filter Module BMW
Compact housing oil module for the BMW 3 Series 6-cylinder petrol engine
The water-cooled oil filter and filter are integrated into this single unit housing. It was made more compact by adapting the plastic cover to the engine design. Since the filter element is made of metal and not plastic, it can be incinerated.

Air Cleaner System
Air Cleaner System with hydrocarbon trap (pleatsorb)
The HC trap consists of activated carbon layers held in place between air-permeable supporting media. This design provides a large, effective surface area and reduces pressure losses through the special arrangement of pleats. Installed in DaimlerChrysler vehicles.
>>Technical Information

Air intake system for the 4-cylinder petrol engine containing an integrated dirty air intake and resonator, intake noise silencer, and clean air intake.
A round filter cartridge is directly attached to the hot film airflow meter (AFT). The filter holder for the element on the rear end cap is pressed between the upper and lower parts of the housing and keeps the element in place. Installed in BMW 1 series.
>>Technical Information

"Europiclonﾂｮ" Air Cleaner
Two-stage air cleaner
Long service life through integrated pre-separation. Corrosion free housing in impact resistant plastic. Metal-free filter elements are easily disposed by incineration and therefore are not only environmentally friendly but also inexpensive to dispose of. High reliability through radial seal on housing. Various accessories and easy adaptation to other equipment with a flexible bracket system.

Oil Separator
Oil Separator L700 DaimlerChrysler -Oil Separator with CCV
Quad-cyclone oil separator. Integrated pressure regulation valve. Mounted on the top of the cylinder head cover.

"ProVent" Oil Separator for Crankcase Ventilation
Less motor oil is consumed because of a more efficient rate of oil separation.

Fuel Filter VW
Crash protected housing fuel filter for all diesel engines in the Golf-platform
