Archives of Past Exhibits:Aisan Industry

2015 JSAE Automotive Engineering Exposition

Power saving fuel pump module

-The Company exhibited the new product for the first time. Installed vehicle: Toyota "Aqua"

Power saving fuel pump module

-The new product features a transversely mounted pressure regulator. It reduces power consumption by 20%.

Conventional fuel pump module (reservoir cup type)

Hydrogen injector for FCV

-Hydrogen injectors control the pressure and flow rate of hydrogen that is to be supplied to fuel cells. Installed vehicle: Toyota "MIRAI"

CNG fuel system (High pressure regulator)

-The product is manufactured in Indonesia. Installed vehicle: Toyota "Corolla" (Thailand)

CNG fuel system (Fuel rail assembly)

-The product is manufactured in Indonesia. Installed vehicle: Toyota "Corolla" (Thailand)

Canister

Installed vehicle: Toyota "Camry" (North America)

Fuel system products (fuel injector)

Fuel system products (fuel pump, fuel pump module)

-The fuel pump adopts a new shape impeller. -The fuel pump module incorporates an electric fuel pump, a pressure regulator, a fuel filter, a fuel level gauge and others.

Intake & exhaust system products (PCV for engines with turbocharger)

-The Company showcased the world's first PCV valve compatible with engines with turbocharger. Installed vehicles: Toyota "Auris" (1.2L, turbocharged), Toyota Lexus "NX" (2.0L, turbocharged)

Intake & exhaust system products (Engine valve)

Intake & exhaust system products (EGR valve)

Intake & exhaust system products (Throttle body)

Intake & exhaust system products (Plastic intake manifold)

2014 JSAE Automotive Engineering Exposition in NAGOYA

Hydrogen injector for FCV

Installed Vehicle: Toyota "MIRAI" -Control the pressure and flow rate of hydrogen that is to be supplied to fuel cells to contribute to high-efficient power generation. Its world premiere.

CNG fuel system

Plastic intake manifold

High pressure regulator

Throttle body

EGR valve

Engine valve

Fuel pump module

Charcoal canister

Fuel injection system for motorcycles

2010 JSAE Automotive Engineering Exposition

Main products

Products development activities

Canister for hybrid vehicles North America		Fuel pump module for flat fuel tank

Image Image Image Image Image Image		Image Image Image Image

EGR valve		Alternative fuel supply system

Image Image		Image (Fuel pump) Image (Fuel pump) Image (Fuel pump) Image (Fuel injector) Image (Fuel injector) Image (Fuel injector)

Fuel pump

Image Image (Improved type) Image (Conventional type) Image (Impeller (Improved type)) Image (Impeller (Conventional type))

Fuel pump		Canister

Image Image		Image Image

Canister integrated fuel pump module


Plastic throttle body		Electronic control throttle body

Image Image Image		Image Image Image

Fuel pump		Fuel pump module

Image Image Image		Image Image

Fuel injector		Charcoal canister

Image Image		Image Image Image

Titanium alloy engine valves		Engine valves

Image		Image

JSAE 2008

Exhibits Highlighting Engine Management Systems


LPG Liquid Fuel Injection System
	Image(Intake manifold with fuel rail) Image(Injector)

Fuel pump
	Image Fuel pump (developed) Image (Fuel pump module) Installed in Nissan Infinity in North America

Charcoal canister compiled with LEV-II regulations
	Image Supplied to almost all Toyota's vehicles in North America

Diesel engine related products
	Image (EGR cooler bypass valve) Image (EGR cooler for T.RAD) Image (Exhaust gas control valve) Image (Diesel throttle body (under development)) Bypass valve is installed in the following vehicles: Avensis, Hilux, Dyna, Toyoace (Toyota)

Titanium Alloy Engine Valve
	Image	Installed vehicles: Lexus IS/F

Intake Air Control Valve
	Image1 Image2	Installed vehicles: LS460

JSAE 2007

Fuel rail W/Fuel injector	Fuel Pump

Fuel Pump Module/Charcoal canister integrated fuel pump module
	Image1 (Fuel Pump Module) Image2 (Charcoal canister integrated fuel pump module) Image3

Charcoal canister	Resin throttle body

Image	Image

Resin intake manifold w/variable induction system	EGR cooler

Image1 Image2	Image

JSAE 2006

Resin throttle body >>Technical Information
<Features>
-Reduced idling revolution as a result of reducing air leakage at full closing throttle valve by adopting wide-bore.
-Disuse of hot water heating by utilization of resin characteristics such as water-shedding and low-thermal conductivity.
-Achieved weight and cost saving by resinification and reducing components.
Electric water pimp for hybrid vehicle >>Technical Information
<Features>
-Long life by using blushless motor.
-Improved reliability by adopting separated pump camper structure which has bulkhead with no water leakage.
Relief valve for fuel vapor-containment system >>Technical Information
-Relief Valve for Fuel Vapor-containment System suitable for Hybrid Electric Vehicles
Resin intake manifold with variable induction system >>Technical Information
-Increased driving performance by improvement in torque characteristics at wide range.
Titanium Alloy Engine Valve >>Technical Information
<Features>
-Super lightweight: 40% weight reduction against heat resisting steel.
