Archives of Past Exhibits: Magneti Marelli

SAE China 2015

High-pressure pump and injectors for gasoline direct injection system

-800 bar, under development

High-pressure pump and injectors for gasoline direct injection system

-600 bar

Intake manifold

Super-light throttle body

-40% lighter than traditional products, not mass production

Modular gasoline throttle body

-Installed: Dongfeng Peugeot Citroen Automobile, 20%-30% lighter than traditional products

Electronic throttle body generation 6

BSG (Belt driven starter generator) motor

Battery management components

Efficient transmission system

2015 IAA Frankfurt Motor Show

Instrument cluster

Installed vehicle: Fiat "500"

Instrument cluster

Installed vehicle: Jeep "Renegade"

Instrument cluster

Installed vehicle: Porsche "911 GT3"

Infotainment system

Installed vehicle: Peugeot "308" -Utilizes touchscreen for media, navigation, climate control and driver assist features.

Infotainment system

Installed vehicle: Alfa Romeo "Giulia" -Includes media player, navigation system, and vehicle management options. Operated through rotary knob and touchpad.

Various Telematics Box (TBOX) and telematics units

-TBOX incorporates a phone module, a module which connects to various satellite arrays (GPS, Galileo, GLONASS), and a 3-axes accelerometer. Services that TBOX provides include e-call, e-toll, fleet management, road condition, and vehicle tracking.

500 bar GDI injector and pump and plug top ignition coil

600 bar GDI injector and pump

Electric motor generator

Gen IV Mechatronic automated manual transmission

Dynamic all-LED projector based adaptive lighting headlamp with glarefree high beam

Bi-color LED Tri-function

Multi-LED dual cavity

LED 3D light tubes

LED 2D light tubes

Multi-LED Bi-function

LED Dot-design

Single-LED Reflexion and filament bulb reflexion

Rearlighting options

3D elements

Mirror effect

Light bar

Light tube

Light curtain

Shell reflector

Dot design

Slit design

Film technology

Prismated optic

Shanghai International Automobile Industry Exhibition 2015

Body computer, remote key

-Installed: GAC Fiat

Chassis domain controller

Instrument cluster

Installed vehicle: Jeep “Renegade”

Full LCD color screen instrument cluster

Installed vehicle: Citroen “C4 Picasso”

Instrument cluster

Installed vehicle: Fiat “500”

Instrument cluster

Installed vehicle: Porsche “Macan”

Hydraulic rebound stop strut

-Installed: Dongfeng Peugeot Citroen Automobile

Piston rod

Front shock absorber

Installed vehicle: GAC Fiat Chrysler “Viaggio”

Shock absorber

Installed vehicle: Maserati “Ghibli”

Composite control arm

Lightweight front aluminum knuckle

Pedal box

Installed vehicle: Jeep “Renegade”, Fiat “500X”

Variable thickness stamped muffler

Aesthetic tail pipe

-Installed: Audi

Close coupled front catalyst

Electric motor generator

Power inverter

Gasoline direct pump, gasoline direct injector

-600 bar

Throttle body superlight

GDI (Gasoline direct injection) ECU (Electronic control unit )

Electric gear actuator

Multi functional logger

Electric clutch actuator

Gear and clutch electronic control unit

Ignition coil

Electric generator unit, power inverter

Fast rate camera with realtime H264 compression, 90kW integrated motor generator

Taillight

Installed vehicle: Audi “TT”

SAE China 2014

High-pressure pump for gasoline direct injectors

-It is the world's most advanced product with a pressure relief valve of 600 bar in casting formation to make it single piece. It is under development and will be mass production in 2017.

Injectors

-It is the world's most advanced product of 600 bar in casting formation to make it single piece. It is under development. The double loop injector head has better radiating performance than single one.

BSG (Belt driven starter generator) motor

Motor

Inverter

6th generation throttle body

Superlight throttle body

ECU (Electronic control unit)

2014 Auto China - Beijing International Automotive Exhibition

Telematics system

-Europe only, not sales in China because of automotive regulatory reasons

Instrument cluster

Installed vehicle: Dodge “Dart”

Instrument cluster

Installed vehicle: Dongfeng Citroen “C4 Picasso”

Instrument cluster

Installed vehicle: Porsche “Macan”

Instrument cluster

Installed vehicle: Fiat “500e”

Instrument cluster

Installed vehicle: Fiat “Ottimo”

Instrument cluster

Installed: Qoros

Hybrid FRP front suspension arm & HSS ultra-light front suspension arm

Aluminum knuckle & Rear wheel carrier

Rear wheel carrier installed: BMW

Shock absorbers

Right front strut installed vehicle: GAC Fiat “Viaggio” Second right: Synaptic damping control shock Left: Hydraulic rebound stop strut Second left shock installed vehicle: Maserati “Ghibli”

LED tail lamp with slit layers

Installed: VW

LED tail lamp with light guides

Low-voltage motors, high performance power inverter

Generation IV mechatronic AMT

- Produce in Japan

Dual-clutch transmission actuation system

GDI ECU

Pump, injector

Piston accumulators

Kinetic energy recovery systems, heat exhaust recovery systems

Hydraulic gearbox actuator

Stainless steel stamped exhaust manifold

Spinformed muffler

Injection and mixing module for SCR system

Hand brake lever

Pedal box

Installed vehicle: Alfa Romeo “Mito”

Shanghai International Automobile Industry Exhibition 2013

Hybrid composite front control arm

Single layer HSS front control arm

Hydraulic actuator open

Electronic control unit

Sensor

Synaptic damping control proportional valve

Hydraulic power unit

Shock absorber

Installed vehicle: GAC-Fiat “Viaggio”

Rear lamp

Headlamp

Installed vehicle: Opel “Astra”

Car body computer

Installed:： GAC-AF

Door module

Installed:： Ssang Yong

AL-control

Electronic control unit

Circuit board

Instrument cluster

Installed vehicle: Audi Q5

Instrument cluster

Installed vehicle: GAC-Fiat

Instrument cluster

Installed vehicle: Audi A4

Instrument cluster

Installed:： Qoros

Instrument cluster

Installed vehicle: Maserati “Quattoporte”

Instrument cluster

Installed:： Citroen C4 “Picasso”

Instrument cluster

Installed vehicle: Porsche 911

Rear lamp

Headlamp

Installed vehicle: Audi A7

Inverter

Generator

Injector

Injection pump

Rack transceiver

Hand brake lever

Pedal box

配套车型：标致208

Diesel particulate filter

Stainless steel stamped manifold

Starter battery

Oil filter

Air flow meter

Wire throttle body

Electric motor generator

2012 Auto China - Beijing International Automotive Exhibition

Plastic components & modules Pedal box

Installed vehicle: Fiat New Panda

Plastic components & modules Pedal box

Installed vehicle: Fiat Ducato

Plastic components & modules Hand brake lever

Installed vehicle: Fiat New Panda

Plastic components & modules Electric throttle control

Installed vehicles: Fiat New Uno new Palio

Exhaust system Diesel Particulate Filter

Exhaust system Stainless steel stamped manifold

Exhaust system Dual mode valve

Exhaust system Close coupled catalyst 1.4 turbo petrol engine

Installed vehicle: GAC Fiat Viaggio

Suspension system Shock absorber

Suspension system U-link rear suspension

Suspension system Aluminum front knuckle

Suspension system Front lower arm

Powertrain ECU S-MIU, pump and throttle body integrated application Bike 1cy1

Powertrain Gasoline Direct Injection(GDI) system

Delhi Auto Expo 2012

Instrument Cluster		Instrument Cluster
	Installed Motorcycle： Rodeo Mahindra		Installed Vehicles： Porsche 911

Instrument Cluster

Installed Vehicles：

Peugeot 508

Installed Vehicles：

Fiat "Linea"

Instrument Cluster

Installed Vehicles：

Peugeot "Satelis"

Installed Vehicles：

Audi "B8", "A5"


Headlamp with BiHalogen Projector and DRL		Bulb Taillamp with Staged Reflector and Reflex
	Installed Vehicles： Opel "Astra GTC"		Installed Vehicles： VW "Polo"

Taillamp with LED and Lightguides

Diesel Common Rail ECU

Installed Vehicles：

Fiat "Punto EVO"

Gasoline MPI ECU		Automated Manual Transmission Gen. 4 "Freechoice"

Electric Motor Generator		Bowden Full Aluminium Throttle Body 46SX
	Output: 20krpm/27kW/30Nm

Gasoline Modular Throttle Body		FlexFuel Air Intake Manifold with Ethanol Cold Start

CNG Air Intake Manifold with Integrated Rail and Magneti Marelli Injectors		Front Wheel Group with Aluminum Knuckle


Ultralight Front Control Arm		Wheel Hub

Cast Iron Front Steering Knuckle		Struts

Lift System Actuators and Hydraulic Electronic Control Unit

In dash computer for Trucks

Installed Vehicles：

Paccar

image image

Voltage Stabilizer for Stop & Start Systems

Door Modules

Installed Vehicles：

SsangYong

Automatic Climate Control Panel

Body Computer

Installed Vehicles：

Alfa Romeo "Giulietta"

Installed Vehicles：

FIASA


Body Computer NPL FIAT India with Power Distribution

Body Computer

Installed Vehicles：

Alfa Romeo "Giulietta"


DOC/DPF Euro 5 System for LCV		Dual Mode Valve for Sound Quality Management

Urea Module Injection with Mixer		Engine Control Unit and Data Logger(For Racing)

F1 Kers Motor Generator Unit

Electric Gear Actuator


SAE World Congress 2011

Electric Motor Generator


Delhi Auto Expo 2010

<Electronic Systems>
Instrument cluster		Instrument cluster
	Installed vehicle : Fiat "Linea"		Installed vehicle : Audi "A4"
Image		Image

Radio navigator		Windows auto in-dash computer

Image		Image

Telematic box		Stand alone immobilizer

Image		Image

Body computer


<Exhaust Systems>
Close coupled catalytic converter integrated to stamped stainless steel manifold		Muffler integrated to PM aftertreatment system

Image		Image

<Powertrain>
Tetrafuel air intake manifold		Tetrafuel ECU

Image		Image

Automated manual transmission	ECU

Image	Image	: For diesel engine
	Image	: For gasoline engine

GDI pump		GDI injector

Image		Image

<Dynamic Systems>
Complete electronic McPherson strut		Rear electronic shock absorber

Image		Image

Controlled valve		ECU

Image		Image

Acceleration sensor


<Suspension Systems>
McPherson front control arm		Twist beam axle

Image		Image

<Shock absorbers>
PowerShock		Hydraulic rebound stop

Image		Image

<Pedal Handbrake Systems>
Pedal box
	Installed vehicle : Fiat "Ducato"

<Automotive Lighting>
Tail lamp		Head lamp with daytime running light
	Installed vehicle : Volkswagen "Polo"		Installed vehicle : Fiat "500"
Image		Image
