Superfast Charging Edition: 4C Superfast charging, recharging 70% SOC in 15 minutes / 200 kWh - 800 kWh battery capacity 500 km / Max. Range; 8 years or 1,200,000 km ultra long life span Long Life Edition: Ultra long life span up to 15 years or 2,000,000 km / 500 km ultra long range / Mountain-shaped design - maximizes chassis space and offers 40% more power than conventional standard batteries. Battery warranty covering the entire service life of the vehicle allows for meticulous cost control.
×
Supplier Database
Commercial Vehicle Solution: Standard H pack for heavy-duty trucks 2024 Auto China - Beijing International Automotive Exhibition CALB Group Co., Ltd. (Formerly CALB Co., Ltd.)
-Adoption of innovative CIR integration technology design, energy density over 160Wh/kg. -New generation of high-rate, long-life 230Ah cells and high-energy, long-cycle 314Ah cells for a system warranty of over 1.2 million kWh. -High-strength aviation-grade aluminum lightweight case to meet the harsh working conditions of heavy-duty trucks and mining trucks.
×
Supplier Database
ECU integrated cell connecting board The Battery Show Europe / Electric & Hybrid Vehicle Technology Expo 2023 Gentherm Inc. (Formerly Amerigon Inc.)
Gentherm ECU integrated Cell Connecting Board eCCB with flex foil conductors, MSP (mechanical structuring process) technology and integrated cell sensing electronics enables to measure critical State of Health (SOH) data for predictive failure & warranty, cell temperature control (inside of cell), SoC of each cell, and cell resistance. Benefits: -Replaces Cell Sensing Electronics, usually with one CSE per module -Reduction of approx. 100 wires for BEV pack -Reduction of wire harness assembly and packing labor -High Voltage Safety (Opto-isolated CAN signals) -EMI improvement and Elimination of NTCs (Integrated into ASIC) -Enhanced reliability through elimination of wires and connectors
×
Supplier Database
High energy density pack IAA TRANSPORTATION 2022 CATL (Contemporary Amperex Technology Co., Ltd.)
The cell to pack technology has a high-strength lightweight modular structure design with a long service life, meeting 8 years or 800,000km warranty requirements (>80% SOH) Techical data Cell capacity: 228 Ah Chemistry: LFP Dimensions: 1060 mm x 630mm x 240 mm Energy: 35.23 kWh Pack energy density: 160 Wh/kg Nominal Voltage (1/3C, 25°C): 154.56 V Operation voltage range: 120 - 175.2 V Charge rate @25°C: 1.0C IP ratings: IP68, IP6K9K Operating Temperature: -35-65°C Certification: ISO26262, ECE R100/R10 Application scenarios: bus, truck, construction machinery et.
×
Supplier Database
ECU integrated cell connecting board (eCCB) The Battery Show Europe / Electric & Hybrid Vehicle Technology Expo 2022 Gentherm Inc. (Formerly Amerigon Inc.)
Gentherm ECU integrated Cell Connecting Board eCCB with flex foil conductors, MSP (mechanical structuring process) technology and integrated cell sensing electronics. It enables to measure critical State of Health (SOH) data for predictive failure & warranty, cell temperature control (inside of cell), SoC of each cell, and cell resistance. Benefits: • Replaces Cell Sensing Electronics, usually with one CSE per module • Reduction of approx. 100 wires for BEV pack and further packaging savings • Reduction of wire harness assembly and packing labor • High Voltage Safety (Opto-isolated CAN signals, not voltage) • EMI improvement and Elimination of NTCs (Integrated into ASIC) • Enhanced reliability through elimination of wires and connectors
×
Supplier Database
ECU integrated cell connecting board The Battery Show Europe / Electric & Hybrid Vehicle Technology Expo Gentherm Inc. (Formerly Amerigon Inc.)
-Gentherm ECU integrated Cell Connecting Board with integrated cell sensing electronic enables the system to measure State of Health (SoH) for predictive failure & warranty, cell temperature control (inside of cell), SoC of each cell, and cell resistance. In addition, modules for electrochemical impedance spectroscopy can be integrated. This creates a completely new and future-oriented battery monitoring system.
×
