The company, which has strength in large components, exhibited a 1.5 x 1 m integrally molded battery housing and a 1.4 m rear torque box. Other products include a rear subframe, front torque box, front spring tower, front subframe, and V8 cylinder block.
×
Supplier Database
Fuel rail with DI-CHG10 injector / DI-CHG15 injector Vienna Motor Symposium 2023 BorgWarner Inc.
BorgWarner' hydrogen injection solutions Fuel Rail Assembly -The one piece forged stainless steel fuel rail assembly features high crashworthiness as well as low noise and stress due to optimized design. Features: -Outer diameter: 30 mm -Thickness: 2.5 mm -M14 X 1.5-6g inlet thread -Operating temperature: -40 to 125 °C -Working pressure range: up to 4,000 Kpa -System Burst pressure: > 4,000 Kpa Hydrogen Fuel Injector -ECU controlled medium pressure fuel injector family for hydrogen internal combustion engines Features: -Nominal pressure range: 20 to 40 bar -Multiple injection capability DI-CHG10: for application up to 60 kW/cylinder; static flow range up to 10 g/s at 40 bar gauge DI-CHG15: for applications up to 90 kW/cylinder; static flow range up to 15 g/s at 40 bar gauge
Fuel Rail Assembly for passenger cars and commercial vehicles -The one piece forged stainless steel fuel rail assembly features high crashworthiness as well as low noise and stress due to optimized design. Features: -Outer diameter: 30 mm -Thickness: 2.5 mm -M14 X 1.5-6g inlet thread -Operating temperature: -40 to 125 °C -Working pressure range: up to 4,000 Kpa -System Burst pressure: > 4,000 Kpa Hydrogen Fuel Injector -ECU controlled medium pressure fuel injector family for hydrogen internal combustion engines Features: -Nominal pressure range: 20 to 40 bar -Multiple injection capability DI-CHG10: for application up to 60 kW/cylinder; static flow range up to 10 g/s at 40 bar gauge
×
Supplier Database
Fuel Rail with DI-CHG10 Injector Vienna Motor Symposium 2022 BorgWarner Inc.
Fuel Rail Assembly -The one piece forged stainless steel fuel rail assembly features high crashworthiness as well as low noise and stress due to optimized design. Features: -Outer diameter: 30 mm -Thickness: 2.5 mm -M14 X 1.5-6g inlet thread -Operating temperature: -40 to 125 °C -Working pressure range: up to 4,000 Kpa -System Burst pressure: > 4,000 Kpa Hydrogen Fuel Injector -ECU controlled medium pressure fuel injector family for hydrogen internal combustion engines Features: -Nominal pressure range: 20 to 40 bar -Multiple injection capability DI-CHG10: for application up to 60 kW/cylinder; static flow range up to 10 g/s at 40 bar gauge DI-CHG15: for applications up to 90 kW/cylinder; static flow range up to 15 g/s at 40 bar gauge
×
Supplier Database
Rear subframe 2019 SAE-China Congress & Exhibition Gestamp Automocion S.A.
